U834
Product Features
Fabricated of #20 gauge stainless steel with #4 satin finish
Holds two 9" diameter jumbo tissue rolls
Product Specs
Body: Fabricated of #20 ga stainless steel with a #4 satin finish with a smooth radius silhouette,
Cabinet Door: Drawn one piece construction, fabricated of #18 gauge stainless steel finished and grain to match cabinet body, Door is secured to body by means of oversized heavy duty rivets,
Tissue Guide: Spring loaded ABS guide,
Spindles: Unit will hold two 9" diameter rolls with a core diameter of 1 3/8" - 3 1/4" (Non-control delivery) by removing the outer spindle,
Locks: Commercial quality, pin tumbler lock.
Overall Size: 20 1/2"W x 12 1/4"H x 5 7/8"D
521mm x 311mm x 149mm
Capacity: Two 9" OD (229mm) jumbo tissue rolls
Installation Instruction
Provide an area on wall at desired or specified location. Unlock cabinet and place unit on wall making sure cabinet is level. Transfer mounting points to surface and drill pilot holes. Secure unit with proper fasteners per application. Load toilet tissue
